主要特點：
(1) 操作配置靈活: 在同一系統中有三種分散頭，可以滿足可以不同樣品的使用要求, 馬達與分散腔相連部分采用機械密封, 專利的設計可以使用物料直接對密封連接進行冷卻和潤滑
(2) 數字轉速顯示，通過旋鈕可以根據不同的樣品進行轉速連續調節
(3) 可以簡單快速地對分散腔進行更換或者清洗
(4) 可以為客戶提供整套裝置: 包括反應釜和管線分散設備, 以及其他外圍設備如Julabo加熱制冷單元, Chemvak真空泵等, 反應釜可以是玻璃，不銹鋼或其他特殊材料,
(5) Kinematica 可以為客戶提供大到150000l/h的管線式連續流分散機, 實驗室小型分散機MT 3000所得到的數據可以為中試和工業放大提供強大的數據支持
技術參數：
(1) 三相無刷高頻馬達，馬達功率: 800 W，非常適合連續工作，通過變頻器控制轉速，電子動態轉速調節與控制,輸出功率會隨樣品粘度變化而變化，保證均質過程在恒定轉速下進行
(2) 運轉平穩，啟動平穩柔和, 不會突然加速變速，過載保護功能
(3) 數字轉速顯示, 最大轉速: 30000rpm
(4) 噪音水平: <75 dB(A) / 30000rpm
(5) 材質: 1.4435/316L 不銹鋼, 外加電鍍層, 堅固耐用防腐蝕, 特制的Teflon軸承, 具有絕佳的機械性能和化學穩定性，可高溫高壓消毒
(6) 電源: 230V / 50 Hz
(7) 工作環境要求: 0-40°C, 95% rel. humidity
(8) 保護等級: IP 20
(9) 執行標準: EMC according to IEC/EN 61000-6-2 / EN 61000-6-3
Safety according to IEC/EN 61010-2-51
(10) 分散頭選型指南:
|
分散頭型號
|
MTG 20/2
|
MTG 30/2
|
MTG 30/4
|
|
定貨號
|
13031020
|
13031030
|
13031031
|
|
Stator/Rotor-Ø
|
20 mm / 15.4 mm
|
30 mm / 24 mm
|
30 mm / 26 mm
|
|
Tip speed (max.)
|
25.0 m/s
|
35.0 m/s
|
34.0 m/s
|
|
Throughput
|
approx. 10 l/min (depends on the
processed media)
|
approx. 15 l/min (depends on the
processed media)
|
approx. 15 l/min (depends on the
processed media)
|
|
Application examples
|
dispersing and mixing of particles in liquid suspending, crushing, wet milling, extracting
preparing of samples for extraction and decomposition of organis material
intensive mixing
and many others...
|
dispersing and mixing of particles in liquid
suspending, crushing, wet milling, extracting
preparing of samples for extraction
and decomposition of organic material
intensive mixing
and many others...
|
producing fine suspensions and emulsions dissolving of solids gasses solutions
separates fibers and cellular material in very small particles extractions
wet milling of solids
and many others...
|
